Features
● WiFi + RF + AC push 0/1-10V dimmer, 1 channel output. LVD
● Output 1 channel 0/1-10V signal, connect with 0/1-10V dimmable driver.
● Tuya APP cloud control, support on/off, brightness adjust, delay turn on/off light, timer run, scene function.
● Voice control, support amazon ECHO and TmallGenie smart speaker.
● 0-10V or 1-10V output selectable by DIP switch.
● 256 levels 0-100% dimming smoothly without any flash.
● Compatibility with RF 2.4G single zone or multiple zone dimming remote control.
● Each L1(WT) controller can also work as WiFi-RF converter, then use Tuya APP to control one or more RF dimming LED controller or driver synchronously.
● Connect with external push switch to achieve on/off and 0-100% dimming function.
● Light on/off fade time 3s selectable.
● Easy to be placed in standard wall junction box behind a push switch.

Download SBL-L1-TW Specification Sheet

0/1-10V Signal Converter
1. Includes RF 0/1-10V dimmer and DMX 0/1-10V decoder.
2. The RF 0/1-10V dimmer output 1 or 4 channel 0/1-10V signal, which is matched with the RF dimming remote control.
3. The DMX 0/1-10V decoder output 4 channel 0/1-10V signal, compatible with DMX512/RDM standard protocol, andset the DMX address by digital tube display key.
