Feature
● AC phase-cut mosfet dimmer, one channel output, Max. 6A.
● To dim and switch single color dimmable LED lamps, traditional incandescent and halogen lights.
● 256 levels 0-100% dimming smoothly without any flash.
● Four dimming mode: Knob, DMX512, 1-10V, RF 2.4GHz.
● Rotate knob to change brightness, support push, push twice and long push operation.
● DMX512 decoder with RDM function.
● Compatible with active or passive 0-10V, 1-10V dimmer.
● Stand-alone dynamic change mode, speed and brightness adjustable.
● Compatibility with RF 2.4G single zone or multiple zone dimming remote control, 15m remote distance.
● Trailing edge dimming or Leading edge dimming selectable.
● Minimum brightness set from 5% to 40%.
● AC output current and temperature detection.
● Over-heat / Over-load protection, recover automatically

Download SK1 Specification Sheet
